Range
|
Resolution
|
Accuracy
|
Remark
|
|
DC Voltage
|
200mV
|
0.1mV
|
±(0.5% of rdg )
|
-- Input Impendence: 1MΩ
- Overload protection: 250V for 200mV range, effective DC or AC 600V for other ranges
|
|
2V
|
1mV
|
±(0.5% of rdg)
|
|
20V
|
10mV
|
±(0.5% of rdg)
|
|
200V
|
100mV
|
±(0.8% of rdg)
|
|
600V
|
1V
|
±(1.2% of rdg)
|
|
AC Voltage
|
200V
|
100mV
|
±(1.2% of rdg)
|
-- FrequencyRange: 40 to 400Hz
-- Response: average, calibrated in rms of sine wave
|
|
600V
|
1V
|
±(1.8% of rdg)
|
|
DC Current
|
200μA
|
0.1μA
|
±(1.0% of rdg)
|
- Overload protection: F 200mA/250V fuse
Note: 10A range: not fused 10A up to 10 seconds
|
|
2mA
|
1μA
|
|
20mA
|
10μA
|
|
200mA
|
100μA
|
±(1.5% of rdg)
|
|
10A
|
10mA
|
±(3.0% of rdg)
|
|
Resistance
|
200Ω
|
0.1Ω
|
±(1.5% of rdg )
|
-- over-load protection: 250V effective value
|
|
2kΩ
|
1Ω
|
±(0.8% of rdg)
|
|
20kΩ
|
10Ω
|
±(0.8% of rdg)
|
|
200kΩ
|
100Ω
|
±(0.8% of rdg)
|
|
2MΩ
|
1kΩ
|
±(2.0% of rdg)
|
|
Transistor hFE Test
|
range
|
TestRange
|
Test Current / voltage
|
|
|
NPN & PNP
|
0-1000
|
Ib=10μA / Vce=3V
|
|
Diode Test
|
Range
|
Resolution
|
Function
|
-- over-load Protection: 250V effective value
-- forward DC current: approximate 1mA
-- Reversed DC voltage: approximate 3.0V
|
|
1mV
|
Display: read approximate forward voltage of diode
|
|
Continuity
|
Range
|
Function
|
-- over-load protection: 250V effective value
-- open circuit voltage: approximate 3.0V
|
|
Built-in buzzer will sound if resistance is lover than 80Ω
|
