Display |
3 1/2 digit LCD |
Measuring Range |
20/200/2000/20000 Lux (1330A also Footcandle for 1334A) 200/2000/20000/200000 Lux (1332A) 20000 lux-reading x 10; 200000 lux-reading x 100 |
Overrange Display |
Hightest digit of (1) is displayed |
Resolution |
0.01 Lux(1330A,1334A) & 0.1 Lux(1332A) |
Accuracy |
+/- 3% rdg +/- 0.5% f.s.(<10,000 lux) +/- 4% rdg +/- 10dgts (>10,000 lux) (calibrated to standard incandescent lamp, 2856 K) |
Repeatability |
±2% |
Temperature Characteristics |
±0.1%℃ |
Measuring Rate |
Approx. 2 times/sec. |
Recorder Output |
DC 2V/f.s. (full scale) (TES-1332A) |
Operating Temperature & Humidity |
0 ° to 40℃ (32℉ to 104 ℉) < 70% R.H. |
Power Source |
one 9V battery |
Dimensions |
100mm(L) x 60mm(W) x 27mm(H) |
Dimension |
135mm(L) x 72mm(W) x 33mm(H) |
Weight |
250g |
Accessories |
Carrying case, 9V battery & Instruction Manual |
