light meter TES-1332A

light meter
Item Number:
light.rang:0.1lux ~200/2000/20000/200000 lux
Availability: In stock
Manufacturer: TES
$ 144.35
$ 133.91
Display3 1/2 digit LCD
Measuring Range20/200/2000/20000 Lux
(1330A also Footcandle for 1334A)
200/2000/20000/200000 Lux (1332A)
20000 lux-reading x 10;
200000 lux-reading x 100
Overrange DisplayHightest digit of (1) is displayed
Resolution0.01 Lux(1330A,1334A) & 0.1 Lux(1332A)
Accuracy+/- 3% rdg +/- 0.5% f.s.(<10,000 lux)
+/- 4% rdg +/- 10dgts (>10,000 lux)
(calibrated to standard incandescent lamp, 2856 K)
Repeatability±2%
Temperature Characteristics±0.1%℃
Measuring RateApprox. 2 times/sec.
Recorder OutputDC 2V/f.s. (full scale) (TES-1332A)
Operating Temperature & Humidity0 ° to 40℃ (32℉ to 104 ℉) < 70% R.H.
Power Sourceone 9V battery
Dimensions100mm(L) x 60mm(W) x 27mm(H)
Dimension135mm(L) x 72mm(W) x 33mm(H)
Weight250g
AccessoriesCarrying case, 9V battery & Instruction Manual
Display3 1/2 digit LCD
Measuring Range20/200/2000/20000 Lux
(1330A also Footcandle for 1334A)
200/2000/20000/200000 Lux (1332A)
20000 lux-reading x 10;
200000 lux-reading x 100
Overrange DisplayHightest digit of (1) is displayed
Resolution0.01 Lux(1330A,1334A) & 0.1 Lux(1332A)
Accuracy+/- 3% rdg +/- 0.5% f.s.(<10,000 lux)
+/- 4% rdg +/- 10dgts (>10,000 lux)
(calibrated to standard incandescent lamp, 2856 K)
Repeatability±2%
Temperature Characteristics±0.1%℃
Measuring RateApprox. 2 times/sec.
Recorder OutputDC 2V/f.s. (full scale) (TES-1332A)
Operating Temperature & Humidity0 ° to 40℃ (32℉ to 104 ℉) < 70% R.H.
Power Sourceone 9V battery
Dimensions100mm(L) x 60mm(W) x 27mm(H)
Dimension135mm(L) x 72mm(W) x 33mm(H)
Weight250g
AccessoriesCarrying case, 9V battery & Instruction Manual
Products specifications
Attribute nameAttribute value
Sensor TypeLUX Meter
ProducerTES
Made inTaiwan
device typePortable
Light Measurement Range0.1lux ~200/2000/20000/200000 lux
Accuracy Light Meter±3%rdg±0.5%f.s
light max20000
