| Battery Types Tested |
Compact storage batteries, Alkali and lead-acid batteries.. |
| Battery Capacity |
0 to 1200AH |
| Resistance |
Ranges : 4mΩ, 40mΩ, 400mΩ, 4Ω, 40Ω, 400Ω
Resolution : 1μΩ , 10μΩ , 100μΩ , 1mΩ , 10mΩ , 100mΩ
Accuracy : 4mΩ：±(3% reading ±20digits) ╱ 40mΩ~400Ω：±(0.8% reading ±6digits) |
| Measurement Condition |
Current : Approx. 40mA, 4mA, 400μA, 40μA, 4μA
Frequency : 1KHz±30Hz |
| DC Voltage |
Range : 6V, 60V
Resolution : 1mV, 10mV
Accuracy : ±(0.1%rdg ±6digits) |
| Temperature |
Range : -20℃ to 60℃ (-4℉ to 140℉)
Resolution :0.1℃ / 0.1℉
Accuracy : ±1℃ / ±1.8℉ |
| DC Current |
Range : 60A , 600A
Resolution : 0.01A , 0.1A
Accuracy : 60A : ±(2%rdg+20dgt) , 600A : ±(2%rdg+2dgt) |
| Open Circuit Voltage |
5V max |
| Manual Data Memory |
999 data sets |
| Continuous Data Memory |
6000 data sets (only use PC download) |
| Comparator |
Setting : Resistance upper and lower limits and voltage
throughold limit.
Memory : 99 sets of values
|
| Operating Environment |
0℃ to 40℃ (32℉ to 104℉), 80%RH or less, non-condensing. |
| Maximum Input Voltage |
60VDC |
| Power Supply or AC Adapter |
Six AA size 1.5V alkaline batteries |
| Battery Life |
5.5 hours |
| Weight |
Approx. 530g including batteries |
| Dimensions |
Approx. 198(L) × 94(W) × 49(H)mm |
| Accessories |
Clip – type test lead with temperature sensor, Pin – type test lead, 3092CP DCA current adaptor, Zero adjustment board, Instruction manual, batteries, AC adaptor, USB cable, CD PC software, Carrying case. |
