TES WM-03 Power Quality Data Logger

4Displays with W, PF, V, A
Easy Plug-in and Test
True RMS measurements
Availability: Out of stock
ریال

TES WM-03 Power Quality Data Logger

Features

  • 4 displays, one each for W, PF, V, A
  • True RMS measurements
  • Easy plug-in and test
  • RS232 serial Interface
  • 1012 points of data logging capability

Applications

Ideal for the following applications: Energy Audits, Measuring Electrical Energy, Electrical Load Studies, Energy Quality Analysis.

Specifications:

TES WM-03 Specifications

Power Range 200W
Accuracy 0.9% rdg. ±4 dgts.
AC/DC Current Range 20A
Accuracy 0.5% rdg. ±3 dgts.
AC/DC Voltage Range 750V
Accuracy 0.5% rdg. ±3 dgts.
Frequency Range 2, 20, 200kHz, 2, 20MHz
Accuracy 0.5% rdg. ±2 dgts.

TES WM-03 Power Quality Data Logger

Features

  • 4 displays, one each for W, PF, V, A
  • True RMS measurements
  • Easy plug-in and test
  • RS232 serial Interface
  • 1012 points of data logging capability

Applications

Ideal for the following applications: Energy Audits, Measuring Electrical Energy, Electrical Load Studies, Energy Quality Analysis.

Specifications:

TES WM-03 Specifications

Power Range 200W
Accuracy 0.9% rdg. ±4 dgts.
AC/DC Current Range 20A
Accuracy 0.5% rdg. ±3 dgts.
AC/DC Voltage Range 750V
Accuracy 0.5% rdg. ±3 dgts.
Frequency Range 2, 20, 200kHz, 2, 20MHz
Accuracy 0.5% rdg. ±2 dgts.
Products specifications
Attribute name Attribute value
Made in Taiwan
Producer TES
device type Portable
گارانتی One Year
Input Voltage AC+DC: 200/750 (dgts 3±rdg % 0.5 ±)
current 20A
Frequency 2K/20K/200K/2M/20MHz
